Ovation Ultra Solidbody 1418 & 1419 Wiring Schematic
passive guitar wiring
Ovation Ultra Solidbody 1418/1419
N/A (passive circuit)
1980s
US
8 components
Hand-drawn wiring schematic for the Ovation Ultra Solidbody models 1418 and 1419 (GS3 designation). Shows a 3-pickup passive configuration with neck, middle, and bridge pickups routed through a 5-way selector switch to master volume and tone potentiometers. Color-coded wiring: red, green, white, and black leads.
Components
neck pickup
middle pickup
bridge pickup
volume potentiometer
tone potentiometer
5-way selector switch
capacitor
output jack
