Ovation Ultra Solidbody 1418 & 1419 Wiring Schematic
Year: 1980
Hand-drawn wiring schematic for the Ovation Ultra Solidbody models 1418 and 1419 (GS3 designation). Shows a 3-pickup passive configuration with neck, middle, and bridge pickups routed through a 5-way selector switch to master volume and tone potentiometers. Color-coded wiring: red, green, white, and black leads.
