Ovation USA Fretwire Engineering Drawings
mechanical engineering drawing (not a circuit)
Ovation USA Fretwire
N/A (mechanical drawing)
1992
US
3 components
2 diagrams
Manufacturing engineering drawings for Ovation Instruments fretwire specifications. Page 1: Standard Fret Wire (#4479, part 95003-C%50) in nickel silver with detailed cross-section dimensions (crown width 0.092 in / 2.34mm, crown height 0.040 in / 1.02mm, tang width 0.022 in / 0.559mm, overall height 0.078 in / 1.98mm). Page 2: Jumbo Bass Fret Wire (#4049, part 95004-C%50) in nickel silver with larger profile (crown width 0.113 in / 2.87mm, crown height 0.046 in / 1.17mm, overall height 0.103 in / 2.61mm). Both feature staggered barbs on both sides of web. Drawn by R. McCloud, dated 5/5/92, scale 10X, size B. Revision history includes original release by N. Gomlinski 7/15/68.
Components
Standard Fret Wire #4479 (part 95003-C%50, nickel silver)
Jumbo (Bass) Fret Wire #4049 (part 95004-C%50, nickel silver)
staggered barbs on both sides of web
